CDHC1015 Special Purpose Antenna | 10 GHz – 15 GHz
Cross-dipole that operates from 10 GHz to 15 GHz. With an integrated hybrid coupler this antenna allows to make left- or right-hand circular polarization. Fully waterproof casing equipped with ABS radome is stiff and durable, made with as few parts as possible to ensure accuracy.
Features and Specifications
Technical Performance
- Wide bandwidth
- Low return loss
- Individual calibration
Design and Surface Treatment
- Protective water-resistant case
- Corrosion-resistant coating
Manufacturing Technology
- Manufactured using a high grade aluminum alloy
- Extremely durable
- High quality SMA type coaxial connector
Product Packaging Includes
- Antenna
Product Parameters
Product identification
- Product Name CDHC1015
- Product Category Special Purpose Antenna
Electrical specifications
- Frequency Range 10 GHz – 15 GHz
- VSWR (max.) 1.6
- VSWR (avg.) 1.2
- Power (CW / Peak) 5 W / 10 W
- Antenna Factor 37 – 42 dB/m
- Polarization Circular (with hybrid)
Physical specifications
- Width 47 mm (1.850 in)
- Height 88 mm (3.465 in)
- Depth 47 mm (1.850 in)
- Weight 0.227 kg (0.500 lb)
Operating conditions
- Rated Temperature Range 0°C – +50°C
- Storage Temperature Range -20°C – +70°C
Parameters and Performance
Typical parameters
VSWR
Gain
Antenna Factor
Beamwidth
Port A, E plane
Port A, H plane
Radiation Patterns
measured against lin. pol. 10 GHz
measured against lin. pol. 11 GHz
measured against lin. pol. 12 GHz
measured against lin. pol. 13 GHz
measured against lin. pol. 14 GHz
measured against lin. pol. 15 GHz
measured against circ. pol. 10 GHz
measured against circ. pol. 11 GHz
measured against circ. pol. 12 GHz
measured against circ. pol. 13 GHz
measured against circ. pol. 14 GHz
measured against circ. pol. 15 GHz
Packaging and Accessories
What's in a box
- CDHC1015 Antenna
- Factory calibration certificate
- Full calibration report of each antenna
- Calibration test dataset (available online)
Accessories
- Standard mounting flange
-
Factory calibration report
Custom services
- Custom mounting solutions
- Custom calibration data
