FHA42G9 Special Purpose Antenna | 18 GHz – 26.5 GHz
This precision feed horn antenna covers the 18 to 26.5 GHz frequency range, offering excellent radiation stability and low return loss across the full band. Designed for reflector feeds, antenna measurements, and broadband communication systems, it ensures reliable performance in demanding applications.
Frequency Range
18 GHz – 26.5 GHz
VSWR (avg.)
1.2
Gain
8 – 10 dBi
Impedance
50 Ohm
Connector
K (female)
Power (CW / Peak)
25 W / 50 W
Polarization
Linear
Select files to be sent by e-mail
Product Highlights
Product Parameters
Product identification
- Product Name FHA42G9
- Product Category Special Purpose Antenna
Electrical specifications
- Frequency Range 18 GHz – 26.5 GHz
- VSWR (max.) 1.5
- VSWR (avg.) 1.2
- Impedance 50 Ohm
- Connector K (female)
- Power (CW / Peak) 25 W / 50 W
- Antenna Factor 45 – 50 dB/m
- Polarization Linear
Physical specifications
- Width 115 mm (4.528 in)
- Height 285 mm (11.220 in)
- Depth 115 mm (4.528 in)
- Weight 0.517 kg (1.140 lb)
Operating conditions
- Rated Temperature Range 0°C – +50°C
- Storage Temperature Range -20°C – +70°C
Parameters and Performance
Typical parameters
VSWR
Gain
Antenna Factor
Beamwidth
Packaging and Accessories
Accessories
- Standard mounting flange
