H-A18-W10 Pyramidal Horn Antenna | 12.4 GHz – 18 GHz
Pyramidal horn antenna with the surface finish from Alodine 2040. H-A18-W10 pyramidal horn antenna is made with precision and care with the latest technology to deliver accurate and reliable antenna measurements. The operating frequency is from 12.4 GHz up to 18 GHz with a flat Gain of 10 dBi. The H-A18-W10 can be supplemented with a corresponding Waveguide to Coax Adapter.
Frequency Range
12.4 GHz – 18 GHz
VSWR (avg.)
1.1
Gain
9 – 12 dBi
In Stock: 1 pcs
Ships in 2 days
Select files to by sent by e-mail
Features and Specifications
Technical Performance
- Wide bandwidth
- Low return loss
Design and Surface Treatment
- Corrosion-resistant coating
Manufacturing Technology
- Manufactured using a high grade aluminum alloy
- Extremely durable
Product Packaging Includes
- Antenna
Product Parameters
Product identification
- Product Name H-A18-W10
- Product Category Pyramidal Horn Antenna
Electrical specifications
- Frequency Range 12.4 GHz – 18 GHz
- VSWR (max.) 1.14
- VSWR (avg.) 1.1
- Waveguide Size WR62
- Waveguide Flange UG-1665/U
Operating conditions
- Rated Temperature Range 0°C – +50°C
- Storage Temperature Range -20°C – +70°C
Parameters and Performance
Typical parameters
VSWR
Gain
Antenna Factor
Beamwidth
Packaging and Accessories
What's in a box
- H-A18-W10 Antenna
Accessories
- Standard mounting flange
