H-A50 Pyramidal Horn Antenna | 33 GHz – 50 GHz
H-A50 is a pyramidal horn antenna covering frequencies from 33 GHz to 50 GHz. Design and manufacturing of the antenna were done with detail on quality and low price. This pyramidal horn antenna is lightweight and small in size, optimal as a feed horn for larger antenna structures such as parabolic antennas, as standard calibration antennas to measure the gain of other antennas.
Frequency Range
33 GHz – 50 GHz
VSWR (avg.)
1.15
Gain
19 – 21 dBi
Impedance
50 Ohm
Power (CW / Peak)
10 W / 20 W
Polarization
Linear
Made on demand
14 days to manufacture
Features and Specifications
Technical Performance
- Wide bandwidth
- Low return loss
- Individual calibration
- Covers 5G frequency band
Design and Surface Treatment
- Corrosion-resistant coating
- Includes standard mount
Manufacturing Technology
- Manufactured using a high grade aluminum alloy
- Extremely durable
- High quality 2.40mm type coaxial connector
Product Packaging Includes
- Adapter with ¼ inch inner thread, supplied with antenna
- Linear polarized pyramidal horn antenna
Product Parameters
Product identification
- Product Name H-A50
- Product Category Pyramidal Horn Antenna
Electrical specifications
- Frequency Range 33 GHz – 50 GHz
- VSWR (max.) 1.35
- VSWR (avg.) 1.15
- Impedance 50 Ohm
- Waveguide Size WR90
- Power (CW / Peak) 10 W / 20 W
- Antenna Factor 41 – 44 dB/m
- Polarization Linear
Physical specifications
- Width 36.4 mm (1.433 in)
- Height 25.9 mm (1.020 in)
- Depth 58.8 mm (2.315 in)
- Weight 0.125 kg (0.276 lb)
Operating conditions
- Rated Temperature Range 0°C – +50°C
- Storage Temperature Range -20°C – +70°C
Mounting flange
- Mounting Adapter with ¼ inch inner thread, supplied with antenna
Parameters and Performance
Typical parameters
VSWR
Gain
AF
Cross Polarization
Packaging and Accessories
What's in a box
- H-A50 Antenna
- Antenna specific mount adapter with ¼ inch inner thread
Accessories
- Standard mounting flange
Custom services
- Custom mounting solutions
- Custom calibration data
