BIA300-10 Biconical Antenna | 30 MHz – 300 MHz

This professional-grade biconical antenna provides continuous broadband coverage from 30 MHz to 300 MHz, eliminating the need for multiple antenna changes during testing. It features an integrated precision balun that ensures excellent impedance matching and highly stable radiation patterns across the entire frequency range. Rugged yet lightweight, it is an ideal solution for radiated emissions testing, immunity measurements, and general spectrum monitoring.

Frequency Range
30 MHz – 300 MHz
VSWR (avg.)
2
Gain
-12 – 5 dBi
Impedance
50 Ohm
Connector
N (female)
Power (CW / Peak)
10 W / 20 W
Polarization
Linear
Document Icon Datasheet
Select files to be sent by e-mail
Made on demand
Lead time 4-8 weeks

Product Highlights

Key Features

  • Premium broadband antenna
  • Precision-tuned for optimal performance
  • Designed for versatile applications

Performance & Versatility

  • Enhanced signal strength

Manufacturing & Technologies

  • In-house production
  • High-grade aluminum alloy

Product Parameters

Product identification

  • Product Name BIA300-10
  • Product Category Biconical Antenna

Electrical specifications

  • Frequency Range 30 MHz – 300 MHz
  • VSWR (max.) 15
  • VSWR (avg.) 2
  • Impedance 50 Ohm
  • Connector N (female)
  • Power (CW / Peak) 10 W / 20 W
  • Antenna Factor 5 – 28 dB/m
  • Polarization Linear

Operating conditions

  • Rated Temperature Range 0°C – +50°C
  • Storage Temperature Range -20°C – +70°C

Physical specifications

  • Width 1370 mm (53.937 in)
  • Height 580 mm (22.835 in)
  • Depth 580 mm (22.835 in)
  • Weight 3.5 kg (7.716 lb)

Mechanical Drawings

Parameters and Performance

Typical parameters

VSWR

BIA300-10 - VSWR

Gain

BIA300-10 - Gain

Antenna Factor

BIA300-10 - Antenna Factor

Packaging and Accessories

What's in a box

  • BIA300-10 Antenna

Accessories

  • Standard mounting flange
BIA300-10 ESSENTIAL
Professional Choice
BIA300-10 PLUS
BIA300-10 PLUS CERTIFIED
Typical antenna data (PDF) with a calibration certificate including pass/fail results
Measured antenna data in digital and machine-readable formats with a calibration certificate
Accredited laboratory calibration certificate with the complete PLUS-level data
Data Level
Typical data
Measured data
Measured data (PLUS level)
Typical data
Interactive charts of measured data with hover effects
Interactive charts of measured data with hover effects
Data Formats
& Features
PDF
Excel, CSV, JSON, XML
Excel, CSV, JSON, XML
No data tables
Data tables included
Data tables included
No analysis
Comparison of typical vs measured
Comparison of typical vs measured
Email support (48h response time)
Email support (24h response time)
Email support (24h response time)
Antenna Data & Certification in Full Detail
